The units that will utilize this change are M25, M35 & M46 Single and tandem pumps that have SAE A Pad. The seal is no longer a square cut out, it is a round seal like a doughnut. The sealing properties are the same as the square one, now it will be easier for you […]
They may be mini in size but they are linear resistant transducers can tell the position of a cylinder and send out a signal to other electronics.These kinds of cylinders have a .002″ repeatability, 500 million inches of travel life, 5000 PSI, zero to 10DC response and they have side connectors that let you mount
Mini Electronic Cylinders and Different Types of Controllers Read More »
The parts that make up a cylinder are; body, pistons that move and the piston rod that is hooked to the piston. There are also end caps that are connected to the cylinder body barrel by way of threads, keeper rings, tie rods or a weld. A rod gland is a cylinder rod that goes
Of course we all know when the hydraulics in the cylinders start to go out, makes our jobs alot harder. It is inevitable the seals will go out from everyday wear and tear, age and seals thinning out. Just don’t use it til you have erosion going on, will cost you more in the long
The pressure control and this control are kind of the same but have some added applications to it. It is a two stage compensator that has two pressure modifications. One goes toward the lower pressure limit and the other for the upper pressure limit. There is a vent line that you will need that goes
Three Series you can get NW – 2500 PSI 2″ – 4″ bore – medium ST – 3000 PSI 2″ – 6″ bore – standard UT – 3000 PSI 2″ – 12″ bore – heavy The second picture is a R2 it is a medium duty air and hydraulic cylinder that has steel construction. The
Hydraulic Cylinders – Different Makes and Models Read More »
When selecting a piston cup you need to consider the pressure range, temperature and the fluid, as well as air the pistons are working in. The main function is on the piston head, plunger or the ram, that is used in hydraulic situations. And take into consideration the industrial sealing plane of the perimeters also.
Listed below are the specs for this series of pump. Vane pump 40 series SAE threaded connection or 4 bolt flange come automatically on the pump Pressure settings SV-40 – 2000 PSI max outlet pressure TV – 40 -1000 PSI max outlet pressure Pressure compensating limits SV – 40 – 400 to 2000 PSI TV
Vane Pump 40 Series Combo Pumps General Inforamtion Read More »
The rod wiper keep the cylinder clean. And there are different kinds depending on the use of it and it surroundings. The outside lip takes off dirt and debris from the rod. They are meant to and designed to work in heavy duty applications. There are the RWK, RWD, RWH and RWHN. Some of these
There are particular units that will determine the flow of a lubricant . There are certain flow signals is found on either on the suction side or discharge side of the pump. Another name for this also can be flow meter, where you need to look. The header system has two groups, simple line or
Automatic Lubrication Procedures – Flow of Lubricant Thru the System Read More »
